The Armor Series is a high-performance automotive window film range engineered for drivers who need more than standard tint. Built with advanced non-metallic nano ceramic technology, this series combines heat rejection, UV protection, low reflectivity, and reinforced 4MIL thickness to create a more comfortable and secure driving experience.
Unlike conventional decorative films, the Armor Series focuses on balanced protection across different vehicle glass positions. The lineup includes AR70 for the front windshield, AR30 for the side windows, and AR18 for the rear windows, allowing installers and vehicle owners to choose different light transmission levels according to application needs.
A key advantage of this series is its 4MIL construction, which offers stronger film body performance and added support for glass integrity. In addition to improving solar control, the film also helps reduce the risk of shattered glass spreading after impact. With 99% UV rejection, 97% infrared rejection, and up to 70% total solar energy rejection, the Armor Series is designed for users who expect both daily comfort and dependable long-term protection.
Series Overview
|
Item |
Description |
|
Series Name |
Armor Series |
|
Product Type |
Automotive Window Film |
|
Technology |
Advanced Nano Ceramic |
|
Film Structure |
Non-Metallic |
|
Thickness |
4MIL |
|
Main Advantages |
Heat rejection, UV protection, low reflection, safety support |
|
Warranty |
8 Years |
|
Recommended Use |
Front windshield, side windows, rear windows |
Model Lineup
|
Model |
Recommended Position |
Main Characteristic |
Best For |
|
AR70 |
Front Windshield |
High visibility with heat rejection |
Drivers who need a clearer forward view |
|
AR30 |
Side Windows |
Strong solar control with deeper shade |
Balanced privacy and insulation |
|
AR18 |
Rear Windows |
Darker appearance with highest TSER |
Rear area privacy and stronger shading |
Performance Specifications
|
Specification |
AR70 (Front) |
AR30 (Side) |
AR18 (Rear) |
|
Application |
Front Windshield |
Side Windows |
Rear Windows |
|
Visible Light Transmission |
70% |
29% |
15% |
|
Total Solar Energy Rejection |
52% |
66% |
70% |
|
UV Rejection |
99% |
99% |
99% |
|
Infrared Rejection |
97% |
97% |
97% |
|
Visible Light Reflection |
8% |
7% |
8% |
|
Thickness |
4MIL |
4MIL |
4MIL |
|
Warranty |
8 Years |
8 Years |
8 Years |
|
Technology |
Nano Ceramic |
Nano Ceramic |
Nano Ceramic |
Core Selling Points
4MIL Reinforced Protection
The Armor Series uses a 4MIL film thickness, making it noticeably stronger than standard window films. This thicker structure helps improve impact resistance and can support glass stability if the window is damaged.
Excellent Heat Blocking Performance
With 52% to 70% total solar energy rejection, the series is designed to reduce solar heat entering the cabin. This helps improve comfort for both drivers and passengers, especially in hot-weather environments.
97% Infrared Rejection
All three models provide 97% infrared rejection, helping lower the amount of infrared heat passing through the glass and contributing to a cooler cabin environment.
99% UV Protection
Each film blocks 99% of UV rays, which helps protect both the vehicle interior and occupants from long-term ultraviolet exposure.
Low Reflection, Clear Viewing Experience
The visible light reflection remains low at 7%–8%, helping the glass maintain a cleaner and more controlled appearance while supporting visual comfort.
Non-Metallic Nano Ceramic Construction
The use of non-metallic nano ceramic technology gives the film a stable performance profile while maintaining a modern, premium finish.
Model-by-Model Description
AR70 – Front Windshield Film
AR70 is developed for the front windshield, where visibility is especially important. With 70% visible light transmission, it allows a brighter and clearer driving view compared with darker film options. At the same time, it still delivers 52% total solar energy rejection, 97% infrared rejection, and 99% UV rejection, making it a practical solution for drivers who want heat reduction without overly sacrificing transparency.
AR30 – Side Window Film
AR30 is intended for side window installation and offers a stronger shading effect with 29% visible light transmission. It provides a good balance between privacy, appearance, and performance. With 66% total solar energy rejection, this model delivers noticeably stronger solar control than AR70 while maintaining the same 97% IR rejection and 99% UV protection.
AR18 – Rear Window Film
AR18 is designed for the rear window area and is the darkest model in the series, with 15% visible light transmission. It also delivers the highest total solar energy rejection at 70%, making it the strongest solar-control option among the three. This model is suitable for users who want a deeper rear-glass tone, increased privacy, and stronger protection against sunlight and heat buildup.
Performance Comparison
|
Comparison Item |
AR70 |
AR30 |
AR18 |
|
Highest Visibility |
Yes |
No |
No |
|
Strongest Solar Energy Rejection |
No |
No |
Yes |
|
Darkest Shade |
No |
No |
Yes |
|
Best for Front Windshield |
Yes |
No |
No |
|
Best for Side Window Privacy |
No |
Yes |
No |
|
Best for Rear Window Shading |
No |
No |
Yes |
Product Benefits by Application
|
Vehicle Area |
Recommended Model |
Main Benefit |
|
Front Windshield |
AR70 |
Brighter visibility with effective heat rejection |
|
Side Windows |
AR30 |
Better privacy and stronger solar control |
|
Rear Windows |
AR18 |
Darker finish and highest TSER performance |
Technical Structure
|
Layer / Feature |
Function |
|
Hard Surface Layer |
Helps improve daily durability |
|
Nano Ceramic Functional Layer |
Supports heat rejection performance |
|
UV Protective Layer |
Blocks harmful ultraviolet rays |
|
Low Reflection Design |
Helps keep the glass appearance cleaner |
|
4MIL Safety Structure |
Adds strength and helps minimize glass shatter spread |
|
Adhesive Layer |
Ensures secure installation |
Website Summary
The Armor Series 4MIL Nano Ceramic Window Film is a practical solution for customers seeking higher-strength automotive glass film with dependable heat-blocking performance. By combining 4MIL thickness, 99% UV rejection, 97% infrared rejection, and up to 70% total solar energy rejection, the series provides a well-rounded upgrade for modern vehicles.
With AR70, AR30, and AR18 assigned to different glazing positions, this lineup gives installers a clearer and more professional way to configure full-vehicle window protection.
