Product Details
The Armor Skin Series is a reinforced automotive window film system developed to improve solar control, glass protection, and everyday driving comfort. Featuring a 3MIL composite structure and an integrated nano ceramic core, the series provides a stronger film body than conventional lightweight tint while maintaining low visible reflection and clear interior visibility.
Rather than using one shade across the entire vehicle, the Armor Skin Series offers a coordinated three-model configuration. AS70 is designed for the front windshield, while AS35 and AS18 provide two different shading levels for side and rear windows. This allows installers to create a complete vehicle solution with consistent technology but different transparency levels for each glass position.
All three models feature 100% UV rejection, an 8-year warranty, and low visible light reflection of only 5%–6%. Infrared rejection reaches up to 96%, while total solar energy rejection ranges from 47% to 65%, helping reduce solar heat entering the cabin without creating an excessively reflective exterior appearance.
Product Overview
|
Product Item |
Product Information |
|
Product Name |
Armor Skin Series 3MIL Safety Nano Ceramic Window Film |
|
Series |
Armor Skin Series |
|
Film Category |
Automotive safety and heat-insulation window film |
|
Core Technology |
5G Multi-Function Composite Platform |
|
Functional Structure |
Integrated Nano Core Layer |
|
Available Models |
AS70, AS35, AS18 |
|
Recommended Glass Areas |
Front windshield, side windows and rear window |
|
Film Thickness |
3MIL |
|
UV Rejection |
100% |
|
Warranty |
8 Years |
Complete Model Specifications
|
Specification |
AS70 |
AS35 |
AS18 |
|
Recommended Application |
Front Windshield |
Side & Rear Windows |
Side & Rear Windows |
|
Visible Light Transmission |
70% |
34% |
17% |
|
Total Solar Energy Rejection |
47% |
58% |
65% |
|
UV Rejection |
100% |
100% |
100% |
|
Infrared Rejection |
92% |
96% |
96% |
|
Visible Light Reflection |
5% |
6% |
6% |
|
Thickness |
3MIL |
3MIL |
3MIL |
|
Warranty |
8 Years |
8 Years |
8 Years |
|
Technology |
Integrated Nano Core Layer |
Integrated Nano Core Layer |
Integrated Nano Core Layer |
Three-Level Vehicle Configuration
AS70 – High-Transparency Front Windshield Film
AS70 is engineered for windshield applications where forward visibility is the primary requirement. Its 70% visible light transmission allows a large amount of natural light to pass through the glass, helping maintain a bright and comfortable driving view.
Despite its high transparency, AS70 provides 92% infrared rejection, 47% total solar energy rejection, and complete UV blocking performance. Its visible light reflection is limited to only 5%, creating a clean and restrained exterior appearance rather than an obvious mirror effect.
|
AS70 Performance Focus |
Result |
|
Visible Light Transmission |
70% |
|
Infrared Rejection |
92% |
|
Total Solar Energy Rejection |
47% |
|
Visible Light Reflection |
5% |
|
Main Positioning |
Clear windshield visibility with balanced solar control |
AS35 – Balanced Side and Rear Window Film
AS35 provides a medium shading level for side and rear glass. With 34% visible light transmission, it creates a more private cabin environment while retaining sufficient natural visibility for normal vehicle use.
This model reaches 96% infrared rejection and 58% total solar energy rejection, making it suitable for customers who want a practical combination of insulation, moderate privacy, and a natural exterior finish.
|
AS35 Performance Focus |
Result |
|
Visible Light Transmission |
34% |
|
Infrared Rejection |
96% |
|
Total Solar Energy Rejection |
58% |
|
Visible Light Reflection |
6% |
|
Main Positioning |
Balanced privacy, visibility and heat control |
AS18 – Deep-Shade Side and Rear Window Film
AS18 is the darkest option in the Armor Skin range. Its 17% visible light transmission creates a deeper glass tone and provides greater interior privacy for side and rear window installations.
AS18 also delivers the strongest total solar control in the series, reaching 65% total solar energy rejection. Combined with 96% infrared rejection, it is suitable for rear passenger areas and customers who prefer a darker vehicle appearance with enhanced heat insulation.
|
AS18 Performance Focus |
Result |
|
Visible Light Transmission |
17% |
|
Infrared Rejection |
96% |
|
Total Solar Energy Rejection |
65% |
|
Visible Light Reflection |
6% |
|
Main Positioning |
Deeper privacy and maximum solar energy rejection |
Key Product Advantages
Reinforced 3MIL Film Body
The Armor Skin Series uses a consistent 3MIL thickness across all three models. The reinforced construction gives the film greater physical substance and supports the protective performance of automotive glass.
Compared with ordinary decorative tint, the 3MIL structure is better suited to customers who consider both solar control and additional glass safety support.
01
Full-Spectrum UV Blocking
Every Armor Skin model provides 100% UV rejection. This helps reduce ultraviolet exposure inside the vehicle and supports the long-term protection of seats, dashboards, trim materials, and other interior surfaces.
02
Up to 96% Infrared Rejection
AS35 and AS18 achieve 96% infrared rejection, while the high-transparency AS70 reaches 92%. This performance helps limit infrared heat transfer through the vehicle glass and improves interior comfort during strong sunlight.
03
Low-Reflection Appearance
Visible light reflection remains between 5% and 6% across the entire series. The glass therefore retains a natural, refined appearance without producing an excessively bright or mirror-like surface.
04
Application-Specific Transparency
Each model is assigned a clear functional position. AS70 prioritizes windshield visibility, AS35 provides balanced shading for side and rear windows, and AS18 creates a darker finish with stronger solar rejection.
05
5G Multi-Function Technology Platform
The Armor Skin Series is built on a 5G multi-function composite platform that integrates multiple functional materials into one film structure. The technology is designed to combine heat insulation, UV protection, visibility, adhesion stability, and glass safety support.
Multi-Layer Construction
|
Functional Layer |
Purpose |
|
Scratch-Resistant Layer |
Protects the upper surface during normal cleaning and use |
|
Nano Ceramic Coating |
Supports stable heat-management performance |
|
High-Performance Optical PET |
Provides clarity, strength, and dimensional stability |
|
Nano Ceramic Adhesive |
Supports secure bonding and functional performance |
|
Release Liner |
Protects the adhesive surface before installation |
The integrated structure allows visible light to pass through according to the selected model while reducing ultraviolet rays and infrared heat.
Performance Selection Guide
|
Customer Requirement |
Recommended Model |
Selection Reason |
|
High-transparency front windshield |
AS70 |
70% visible light transmission |
|
Moderate side-window privacy |
AS35 |
Balanced 34% light transmission |
|
Darker rear passenger area |
AS18 |
17% visible light transmission |
|
Highest infrared rejection |
AS35 or AS18 |
Both provide 96% IR rejection |
|
Highest total solar energy rejection |
AS18 |
65% TSER |
|
Lowest exterior reflection |
AS70 |
Only 5% visible light reflection |
|
Complete vehicle film configuration |
AS70 + AS35 + AS18 |
Different transparency levels with matching technology |
Recommended Full-Vehicle Installation
|
Vehicle Glass Position |
Recommended Film |
Main Function |
|
Front Windshield |
AS70 |
Clear forward visibility and heat reduction |
|
Front Side Windows |
AS35 |
Moderate shade and balanced privacy |
|
Rear Side Windows |
AS35 or AS18 |
Flexible privacy selection |
|
Rear Window |
AS18 |
Darker appearance and stronger solar rejection |
A common full-vehicle combination is AS70 for the windshield, AS35 for the front side windows, and AS18 for the rear passenger and rear glass areas. This configuration creates a gradual shading effect while maintaining consistent nano ceramic technology throughout the vehicle.
Why Choose Armor Skin Series?
|
Feature |
Customer Benefit |
|
3MIL Reinforced Construction |
Adds physical strength and supports glass protection |
|
100% UV Rejection |
Helps protect occupants and vehicle interiors |
|
92%–96% Infrared Rejection |
Reduces infrared heat entering the cabin |
|
47%–65% Solar Energy Rejection |
Provides model-specific heat-control performance |
|
5%–6% Visible Reflection |
Maintains a natural, low-glare glass appearance |
|
Three Transparency Options |
Supports different vehicle areas and privacy requirements |
|
8-Year Warranty |
Provides dependable long-term product assurance |
Website Product Summary
The Armor Skin Series 3MIL Safety Nano Ceramic Window Film is a complete vehicle-glass solution that combines reinforced film construction with advanced solar-control performance. Its three-model system allows professional installers to match transparency and heat rejection to the front windshield, side windows, and rear glass.
With 100% UV rejection, up to 96% infrared rejection, low visible reflection, and an integrated nano ceramic core, the Armor Skin Series delivers a practical balance of visibility, privacy, thermal comfort, and protective performance.
